Automatic PET Bottle Unscrambler Machine
The vial ordering machine is suitable for unscrambling PET bottles, arranging them in order, and then discharging them by a vacuum conveyor.
Product Description
Introduction of PET Bottle Unscrambler Machine
The automatic bottle unscrambler machine is suitable for unscrambling PET bottles, arranging them in order, and then discharging them by a vacuum conveyor. It is easily combined with all kinds of filling machinery and filling lines.
Features of PET Bottle Unscrambler Machine
- PLC control, full-automatic system
- The torque limit component of this antibiotic liquid injectable equipment is designed for the main motor reducer in order to protect the bottle unscrambler machine if malfunctions occur
- Two put-casts in one cycle ensure that every work location should working with one bottle, which enhances bottle output efficiency
- The bottles are neck locked through the air conveyor to avoid overturn in delivery
- Dilapidated bottles will be removed by a special device
- A lock detector is equipped with alarming; When locked, the machine will automatically stop
- A photoelectric switch is set for starting when there is bottles and stopping when there are no bottles
- An oil pump will readily fill up the gears, bearings, and the cams
- Maintenance doors and mould replacement doors are provided
- Machine outer tank, revolving tank and bottle receiver component are all Stainless steel AISI304. Frame component adopts high-grade carbon jointing
Technical Data
| Model | SED-12LP-C | |||
| Host Size (m) | Diameter 2.0 Height 1.8 | |||
| Lifting Size (L*W*H m) | 3*1.2*2.8 | |||
| Production Capability (bottles/hr) | 800 | |||
| Gas Consumption (m³/min) | 0 | |||
| Bottle Application | Customized Bottle Type | |||
| Main Motor Power (kW) | 3 | |||
| Total Weight (kg) | 750 | |||
