Automatic Glass Ampoule Filling and Sealing Machine Laboratory
The Automatic Glass Ampoule Filling and Sealing Machine is designed to work in a sterile workspace.
Product Description
Introduction of Ampoule Filling and Sealing Machine
The compact ampoule filling sealing machine is one of the ampoule injectable equipment specially designed for simultaneous filling and sealing operations to maximize efficiency. It is a machine designed to work in a sterile workplace and is known for its simplicity, operational reliability, and minimal maintenance requirements.
The Automatic ampoule filling and sealing machine adopts the rectangular way to transfer ampoules, in such case, the transferring is steady, with a lower braking rate. A new type of clutch is mounted under the ampoule feeding hopper; therefore, the ampoule can be stopped at any time while the machines are still running. That way the ampoule consumption can be reduced. The electromagnetic switch is replaced with a mechanical way in the part of the filling stop system: making it more reliable and durable.
Features of Ampoule Filling and Sealing Machine
- Designed and constructed for efficient and long-term use, the machine complies with GMP standards
- Easy to operate and maintain
- Fine-Setting fill pumps ensure accurate liquid closings; all liquid passage components can be easily disassembled for thorough cleaning and sterilization
- High flexibility and capacity to process all sizes of ampoules
- No-Ampoule-No-Fill ampoules system avoids liquid loss & spillage
- A wide choice of optional units is available
- Variable fill speed and individual flame nozzle controls guarantee quality and complete seals
- Both RPE and After-Flushings of inert gas are possible
The Structure of Ampoule Filling and Sealing Machine
- Automatic loading on stainless steel belt
- “No ampoule – No liquid” function
- A dispensing system with stainless steel rotary piston pumps
- Centralised and individual micrometric dispensing adjustments
- Automatic ignition of the flame unit
- Sealing station
- Exhaust fumes extractor
- Automatic unloading on tray
Technical Data
Parameters | Unit | Model | |||||||||||
SED-2ALG-C | SED-4ALG-C | SED-6ALG-C | SED-8ALG-C | ||||||||||
Filling volume | ml | 1-2 | 5-10 | 5-10 | 20 | 1-2 | 5-10 | 5-20 | 1-2 | 5-10 | 5-20 | ||
Capacity | Pcs/hour | 1800-3600 | 6000-8000 | 3600-6000 | 10000 | 5000-10000 | 14400 | 7000-14400 | |||||
Filling heads | pcs | 2 | 4 | 6 | 8 | ||||||||
Total power | kw | 0.37 | 0.75 | 0.75 | 0.75 | ||||||||
Gas consumption | m³/h | 1-2 | 1-2 | 1-2 | 1-2 | ||||||||
Pressure | MPa | 0.08-0.1 | 0.08-0.1 | 0.08-0.1 | 0.08-0.1 | ||||||||
Power supply | V/Hz | 380V50Hz | |||||||||||
Weight | kg | 400 | 450 | 800 | 1000 | ||||||||
Overall Dimensions | mm | 1500x930x1300 | 1500X930X1300 | 1700X1030X1500 | 1800X1030X1500 |
