Automatic Sleeve Shrink Wrapping Machine for Bottles

An automatic sleeve shrink wrapping machine is designed for fully automatic packaging, which is suitable for the combination of products without bottom support shrink packaging.




Product Description

Introduction of Automatic Shrink Wrapping Machine

The Automatic Shrink Wrapping Machine is designed for fully automatic packaging, which is suitable for the combination of products without bottom support shrink packaging.

The high-quality shrink wrap sealer machine is a compact type of apparatus which is composed of a sealer and a tunnel. It enables multipacks of different sizes or products to be packaged together. Common items include vases, jars, cans, pots, bottles and so on.

Features of Automatic Shrink Wrapping Machine

  • Imported electrical components
  • Different shapes of products can be packed
  • The frequency inverter controls transmission speed which has the function of infinitive speed
  • Specially designed sealing knife makes sealing firm: no cracking and no sticking
  • Simple operation
  • Safe and convenient
  • Automatic feeding, pushing, film feeding, sealing, and cutting
  • Mainly uses PE shrink film
  • Stainless-steel frame for long service life
  • Features a photoelectric eye, which detects the product

Application of Automatic Shrink Wrapping Machine

The automatic shrink wrapping machine is ideal for applications ranging from pharmaceuticals, daily chemicals, cosmetics, food, and beverage with paper trays or without paper trays, etc. And it also can be used for electrical appliances, auto parts, furniture, flooring and other individual or group shrink wrap requirements.



Technical Data
ModelSED-500RSSED-1000RS
Level Height of Feeding850±50mm850±50mm
Width of Packing FilmMax.350mmMax.550mm
Max Packing Size200×140×100mm400×250×250mm
Capacity10-25packages/min10-20packages/min
Working Pressure0.5MPa0.6MPa
Power Supply380V 60Hz380V 60Hz
Power of Machine5.007kW18.8kW
Actual Consumption of Work Power3kW12.8kW
Overall Dimensions2850×1800×1470mm3850×1160×1700mm
Total Weight300kg500kg
Main Material304 Stainless Steel
