Industrial Grinding Machine Small Scale
The Industrial Grinding Machine plays a critical role in many industries. They are often used for industrial food milling, spice grinding, pharmaceutical grinding, chemicals and mineral size reduction, and more.
Product Description
Introduction of Industrial Grinding Machine
This industrial grinder machine is suitable for crushing thermal sensitive material and granulating damp material. The sieve connected to the stator is made of a stainless-steel plate. The gap between the crushing blade and sieve can be adjusted. Can treat material that is adhesive, in a viscous gum, heated or damp state.
The Industrial Grinding Machine plays a critical role in many industries. They are often used for industrial food milling, spice grinding, pharmaceutical grinding, chemicals and mineral size reduction, and more.
Features of Industrial Grinding Machine
- Easy to install and maintain
- Made with stainless steel, complies with GMP standards
- Economical with low cost
- Widely used in pharmaceutical, food, chemical and other industries
- The grinding degree can be adjusted
- This industrial grinding mill is very durable and not easily damaged
Application of Industrial Grinding Machine
Mill grinding machine is widely used for wet & dry granulation or pulverization in pharmaceutical, chemical, bulk drug, cosmetic, colour pigments, food, and other industries.
This industrial grinding mill can be connected with granulating equipment to work together
- Table type: Widely used in crushing and pelletizing of non-uniform materials.
- Inclined type: Normal type, suitable for lighter proportion materials granulation. Popularly used in small batch production.
- Pipeline type: Pipeline connection, either single or joint use is available. No dust is generated when used in combination.
Technical Data
| Model | Spring Length (mm) | Screen Diameter(mm) | Capacity (kg/h) | Motor Power (kW) | Rotation Speed(r/min) | Overall Dimension(mm) | Approx Weight (kg) |
| Table Type | |||||||
| 80 | 55 | 1-8 | 20-50 | 0.55 | Normal 2800 r/min or Frequency 300-3600 r/min | 780×280×750 | 50 |
| 120 | 80 | 1-8 | 100-200 | 1.1 | Frequency 200-1500r/min or 400-300r/min | 850×450×1100 | 150 |
| 160 | 120 | 1-8 | 100-300 | 1.5 | 900×500×1480 | 180 | |
| 180 | 135 | 1-8 | 100-400 | 1.5-2 | 1000*520*1480 | 200 | |
| 200 | 140 | 1-8 | 200-500 | 2.2-3 | 1250×500×1450 | 250 | |
| Pipeline Type | |||||||
| 160 | 120 | 1-8 | 150-300 | 1.5 | Frequency 200-1500r/min or 400-300r/min | 1000*720*1170 | 140 |
| 180 | 135 | 1-8 | 150-400 | 1.5 | 1050*720*1200 | 160 | |
| 200 | 140 | 1-8 | 200-500 | 1.5-2.2 | 1100*750*1300 | 190 | |
| 250 | 180 | 1-8 | 300-1000 | 2.2-3 | 1350*800*1550 | 260 | |
| Inclined Type | |||||||
| 140 | 185 | 1-8 | 80-200 | 1.5 | Frequency 200-1450r/min | 800*900*1100 | 160 |
| 200 | 205 | 1-8 | 150-600 | 2.2 | 900*900*1150 | 210 | |
| 250 | 265 | 1-8 | 150-1500 | 4 | 1100*1000*1250 | 250 | |
