SED-CZ Series Stainless Steel Pure Steam Autoclave Steam Sterilizer
Pipeline system: It adopts the energy pipeline and energy valve which are both 316L sanitary grade materials; Heat-resisting air-operated valve is reliable and its use life is long. The vacuum pump has the advantages of low noise and high vacuum degree.
Product Description
Feature of Pure Steam Autoclave Steam Sterilizer
- Basic function: The system is especially suitable for sterilizing clothes in the hundred-grade sanitary range and for other items to be used in high-standard non-bacteria sites, filled containers or others. The equipment adopts saturated steam as the sterilizing medium. It is mainly used in materials in wet and hot sterilizing operations. The automatic autoclave steam sterilizer has functions of both pulsation vacuum removing cold air and vacuum drying.
- Equipment body: Horizontal rectangle structure. High-quality acid-proof stainless steel 316L inner chamber, stainless steel wiring-drawing plate for decoration deck. All of the angles of the equipment adopt an arc shape, cleaning is simple with no dead angles. The sealing door can adopt an air-driven door or mechanical door. The equipment has GMP standard certification.
- Control system: Automatic autoclave steam sterilizer can adopt computer-control or PLC + touch screen system. The system inspects temperature correctly and runs steadily. It has complete sterilizing records.
Application of Pure Steam Autoclave Steam Sterilizer
Technical Data
| Specification Main Parameter | SED-0.25CZ | SED-0.36CZ | SED-0.6CZ | SED-1.2CZ | SED-1.5CZ | SED-2.5CZ | SED-5CZ |
| Volume | 0.25 | 0.36 | 0.6 | 1.2 | 1.5 | 2.5 | 5.0 |
| Inner Size (mm) | 1000× 500×500 | 1020× 550×650 | 1240× 660×750 | 1500× 750×1050 | 1500× 750×1050 | 1670× 1000×1500 | 3340× 1000×1500 |
| Outer Size (mm) | 1290× 1250×1700 | 1310× 1250×1800 | 1530× 1350×1800 | 1790× 1450×1900 | 1790× 1450×1900 | 1970× 1880×2200 | 3640× 1880×2200 |
| Steam Consumer | 15 | 20 | 30 | 40 | 50 | 80 | 150 |
| Washing Water | 40 | 45 | 50 | 60 | 70 | 80 | 100 |
| Power | 3 | 3 | 3 | 4 | 4 | 5 | 6 |
| Compressed Air | 0.5-0.8 | 0.5-0.8 | 0.5-0.8 | 0.5-0.8 | 0.5-0.8 | 0.5-0.8 | 0.5-0.8 |
| Net Weight | 1000 | 1200 | 1600 | 2100 | 2500 | 3500 | 5000 |
| Design Pressure | 0.245 | ||||||
| Design Temperature | 139 | ||||||
