Semi-Automatic Capsule Filling Machine
The Semi-Automatic Capsule Filling Machine is a special capsule filling machine which is suitable for medium and small pharmaceutical factories, hospital preparation labs, etc. The machine adopts a programmable control system, touch panel operation, automated transduction speed-shift, and an electronic automatic counter. It automatically completes the action of positioning, separation, filling, locking, etc. The dosage is accurate, and operating is simple and convenient.
Product Description
Introduction of Semi-Automatic Capsule Filling Machine
The Semi-Automatic Capsule Filling Machine is a special capsule filling machine which is suitable for medium and small pharmaceutical factories, hospital preparation labs, etc. The machine adopts a programmable control system, touch panel operation, automated transduction speed-shift, and an electronic automatic counter. It automatically completes the action of positioning, separation, filling, locking, etc. The dosage is accurate, and operating is simple and convenient. The machine is made of stainless steel, and it is well suited for capsules which are filled with powder or grain.
Features of Semi-Automatic Capsule Filling Machine
- It adopts a cycloid motor minimizes the noise level while running the machine. These three cycloid motors are in this machine.
- Adopts touch button for operating. However, adding powder into the controlling system will be challenging.
- Easy for changing mould from Size 00 to 5#.
- The machine body is made of stainless steel, the capsule feeder is copper, the capsule disk is an aluminum disk, and the capsule locking position is copper.
- (For details please see the following mould list)
Technical Data
| Model | SED-BJ-I-A | SED-BJ-I-F | SED-BJ-III-A | SED-BJ-III-F | SED-BJ-IV-A | SED-BJ-IV-F |
| Capsule Size | No. 000#-5# | |||||
| Capacity (capsules/hr) | 10000-22500 | 10000-22500 | 20000-40000 | |||
| Power Supply | 220/380V 1/3Pharse 2.1kW | 220/380V 1/3Pharse 4 kW | 220/380V 1/3Pharse 5 kW | |||
| Vacuum Pump (m³/hr) | 40 | |||||
| Capacity of Air Compressor | 0.03m³/min 0.7Mpa | |||||
| Overall Dimensions (mm) | 1200*700*1600 | 1140*700*1630 | 1300*700*1650 | |||
| Weight (kg) | 330 | 420 | 420 | |||
