Automatic Vertical Cartoning Machine SED-LZH
SED-LZH Series automatic vertical cartoning machine is engineered to form, tuck, and close chipboard cartons. It is suitable for packaging products that can be supplied by gravity, and which are sold by weight or volume. Such as rice, grain, dry pasta, etc.
Product Description
Description of Automatic Vertical Cartoning Machine
SED-LZH Series automatic vertical cartoning machine is engineered to form, tuck and close chipboard cartons.
The vertical case erector is suitable for packaging products that can be supplied by gravity, and which are sold by weight or volume. Such as rice, grain, dry pasta, etc.
How Does an Automatic Vertical Cartoner Work?
Different from the horizontal cartoner, a vertical carton packaging machine will pick up a single piece from a stack of folded cartons and then get it to stand up straight, or erect. The continuous motion cartoner will fill it with a product or a number of products vertically through an end that is open, mostly from the top of the machine, and then close it by tucking an end flap of the carton or putting on glue or adhesive. Automatically detects and rejects if lacking leaflet or product and finished product out.
Working steps are as follows:
leaflet fold (1-4 folds) -> feeding -> leaflet detecting -> carton opening and forming -> pushing products and leaflet into carton -> printing batch number -> sealing carton with tuck -> in or hot melt glue device
Features of Automatic Vertical Cartoning Machine
- No products detected, stops working
- PLC control
- Color touch screen
- Compact footprint
- High-speed, accurate rotary carton feeder
- Easy to changeover
- Wide applications: Beauty, health, pharmaceutical, medicinal, liquids, gels, creams, solids, widgets
- Servo-driven rotary carton setup
- Various filling capabilities
Application of Vertical Carton Box Packing Machine
- Personal Care
- Pharmaceutical
- Bakery Products & Mix
- Confectionary
- Dry Pasta
- Ingredient Pouches
- Pet Food
- Pouched Snack Products
- Powdered & Granular Products
- Nutritional Products
- Rice, Grains & Cereal
- Soap & Detergent
Technical Data
| Model | SED-80LZH-C | SED-120LZH5-A | SED-120LZH12-A | SED-120LZH-A | SED-120LZHG-A | SED-120LZHG-A | |
| Encasing Speed (boxes/min) | 60-80 | 30-120 | |||||
| Box | Quality Requirement | 250-350g/㎡ (Base on carton size) | |||||
| Dimension Range（L×W×H mm） | （65-150）×（30-85）×（12-45） | （65-125）×（30-85）×（12-50） | （65-155）×（30-85）×（15-50） | （65-120）×（30-85）×（15-55） | |||
| Leaflet | Quality Requirement | 60-70g/㎡ | |||||
| Unfolded leaflet specification (L x W mm) | 130× 90 | （80-250）×（90-170） | |||||
| Fold Range | 1-4 (Fold) | ||||||
| Compressed air | Working Pressure | ≥0.6mpa | |||||
| Air Consumption (L/min) | 120-160 | 260-300 | 260-300 | 120-160 | 120-160 | 120-160 | |
| Power Supply | 380V 50Hz | 220V 50Hz | |||||
| Main Motor Power (kW) | 1.5 | 1.1 | 1.1 | 0.75 | 0.75 | 0.75 | |
| Machine Dimension(L×W×H mm) | 1200×990×1700 | 2880×1140×1800 | 2880×1140×1800 | 2150×1140×1800 | 2300×1140×1800 | 2700×1140×1800 | |
| Machine Weight (kg) | 1100 | 1500 | 1500 | 1100 | 1200 | 1200 | |
