High Speed Cartoning Machine Horizontal SED-GZH
SED-GZH high-speed cartoning machine is a fully automatic continuous cartoning machine, which is suitable for automatic processing of aluminum-plastic blister plates, bottles, hoses, soft double aluminum, bag-like items, etc.
Product Description
Introduction of High-Speed Cartoning Machine
SED-GZH high-speed cartoner machine is a self-innovated model developed by our company on the basis of a number of advanced technologies at home and abroad, manufactured in strict accordance with the “GMP” requirements of the pharmaceutical industry.
The high-speed carton erector machine has high stability features, a simple structure and easy-to-understand operation. Technically, manual automatic folding and transmission, carton suction molding, multi-station servo follow-up feeding mechanism, etc. have reached the advanced level of the industry.
The high-speed horizontal cartoning machine can be used independently or it can be connected to blister packing machines or other machines as part of a production line with high efficiency.
Features of Horizontal High-Speed Cartoning Machine
- PLC control system
- GMP standard
- Leaflet folding, carton opening, encasing, date coding, and carton closing automatically
- Horizontal continuous motion
- Multi-station pushing mechanism
- Various filling capabilities
- Automatic shutdown without carton or leaflet
- High speed cartoner stops automatically and displays error if in trouble
Application of High-Speed Cartoning Machine
- This high-speed case erector is applicable for encasing marry kinds and specifications of pharmaceutical blisters together with similar products.
- Common applications: Health, beauty, medical, medicinal
- Common products: Creams, gels
Technical Data
| Model | SED-180GZH-A | SED-260GZH-A | SED-450GZH-A | SED-600GZH-A | |
| Speed (cartons/min) | 30-100 | 260 | 450 | 600 | |
| Carton | Quality requirement (g/㎡) | 250-350 (Depends on the size of the carton) | 350 | 350 | |
| Size （L*W*H mm） | (70-165)*(35-85)*(14-50) | (70-180)*(35-80)*(14-50) | (70-180)*(35-80)*(14-50) | (70-180)*(35-80)*(14-50) | |
| Leaflet | Quality requirement (g/㎡) | 60-70 | 60 | 60-70 | |
| Unfolded size range (L*W mm) | (80-250)*(90-170) | ||||
| Folded size range | 1-4 folds | ||||
| Compressed air | Work pressure (MPa) | ≥0.6 | |||
| Air consumption (L/min) | About 120-180 | About 160-200 | About 220-240 | About 220-240 | |
| Supply | 380V 50Hz | ||||
| Main motor power (kW) | 4.5 | 5 | 4.5 | 15 | |
| Dimension （L*W*H mm） | 3650*1560*2040 | 4800*1600*1860 | 4800*1800*2000 | 5100*1850*2000 | |
| Net weight (kg) | About 1750 | About 3000 | About 5500 | About 5500 | |
