SED-GFX Oral Liquid Filling, Stoppering and Capping Machine
SED-GFX Liquid Filling, Stoppering and Capping Machine is applicable for filling, stopper adding and capping 15-500 ml glass or plastic bottles.
Product Description
Introduction of Liquid Filling, Stoppering and Capping Machine
SED-GFX Liquid Filling Stoppering Capping Machine is applicable for filling, stopper adding and capping 15-500 ml glass or plastic bottles. It adopts the linear type filling; a mechanic way to stoppering; cap putting and clamp or screw cap.
The machine is composed of a conveyor, SS316L volumetric piston pump, top-bottom filling nozzles, liquid buffer tank, bottle index wheel, and a capping system.
Applications of Liquid Filling, Stoppering and Capping Machine
Great for pharmaceutical, diagnostic, food, and cosmetic applications. Process a wide array of light plastic and glass containers, plug/tips, screw caps, and brush tip caps. A machine can also process rubber stoppers into serum vials.
Liquid Filling Stoppering and Capping Machine can be connected to an automatic bottle labelling machine to attach labels to finished products.
Technical Data
Name | SED-2GFX | SED-4GFX |
Type of Bottle | Various kinds of plastic/glass bottle | |
Bottle Size | Min. Ø 20 mm Max. Ø80 mm | |
Kind of Cap | Alternative Screw on cap, alum. ROPP cap | |
Cap Size | Ø 20~ Ø45mm | |
Filing Nozzles | 4 heads | 2 heads |
Speed | 50bpm on 30ml | 1000bph on 50ml |
Alternative Filling Volume | 15~60ml, 30~125ml, 50~250ml, 200~500ml | |
Filling Accuracy | ±1% | |
Power | 220V 50/60Hz 1.2kW | |
Compress Air Require | 10L/min, 4~6bar | |
Machine Size (L*W*H) | 2500mm * 1000mm * 1600mm | |
Machine Weight | 800kg |
