SED-RZ Series Vacuum Homogeneous Emulsifying Mixer Machine
Vacuum Homogeneous emulsifying mixer machine is made up of a homogenizer & middle blade stirrer & scraper residues stirrer to form the best mixing setup order to produce the perfect mixed material.
Product Description
Introduction of Vacuum Homogeneous Emulsifying Mixer Machine
Vacuum Homogeneous emulsifying mixer machine is made up of a homogenizer & middle blade stirrer & scraper residues stirrer to form the best mixing setup order to produce the perfect mixed material. By extracting air from the material, the vacuum pump can ensure that the material is glossy, exquisite, and ductile.
Applications of Vacuum Emulsifying Machine
The vacuum emulsifying machine is mainly applied in industries such as daily chemical care products, biopharmaceutical, food, paint and ink, nanometer materials, petrochemical, printing and dyeing auxiliaries, pulp & paper, pesticide, fertilizer, plastic & rubber, electrics and electronics, fine chemicals, etc.
Features of Vacuum Emulsifying Machine
- The vacuum emulsifying mixer machine produced by our company vary in a variety of functions available. The homogenizing systems include upper homogenization, lower homogenization, internal and external circulating homogenization. The mixing systems include single-way mixing, double-way mixing and helical ribbon mixing. The lifting systems include single -cylinder lifting and double-cylinder lifting. High-quality machines can be customized according to customer’s requirements.
- The triple mixing adopts the imported frequency converter for speed adjustment, which can meet different technological demands.
- The homogenizing structure is made with German technology and adopts the imported double-end mechanical seal effect. The maximum emulsifying rotation speed can reach 4,200rpm and highest shearing fineness can reach 0.2-5μm.
- The vacuum defoaming can make the materials meet the requirement of being aseptic. The vacuum material sucking is adopted, and especially for the powder materials, vacuum sucking can avoid dust.
- The emulsifying pot lid adopts the lifting system, easy to clean and the cleaning effect is more obvious, the emulsifying pot can adopt tilt discharge.
- The pot body is welded by imported three-layer stainless steel plate. The tank body and pipes adopt mirror polishing, which fully meet international standards.
Technical Data
Model | Effective Capcity | Emulsifying Motor | Agitator | Vacuum pump | Heating power | ||||
kW | R/min | kW | R/min | kW | Limit Vacuum | Electric heating | Steam heating | ||
SED-10 | 10 | 0.55 | 0-3600 | 0.37 | 0-85 | 0.37 | -0.09 | 6 | 2 |
VME-B20 | 20 | 0.75 | 0-3600 | 0.37 | 0-85 | 0.37 | -0.09 | 9 | 3 |
VME-B50 | 50 | 2.2 | 0-3600 | 0.75 | 0-80 | 0.75 | -0.09 | 12 | 4 |
VME-B100 | 100 | 4 | 0-3500 | 1.5 | 0-75 | 1.5 | -0.09 | 24 | 9 |
VME-B150 | 150 | 4 | 0-3500 | 1.5 | 0-75 | 1.5 | -0.09 | 24 | 9 |
VME-C200 | 200 | 5.5 | 0-3300 | 1.5 | 0-65 | 2.2 | -0.09 | 28 | 10 |
VME-C300 | 300 | 5.5 | 0-3300 | 2.2 | 0-65 | 2.2 | -0.085 | 32 | 12 |
VME-C500 | 500 | 7.5 | 0-3300 | 4 | 0-60 | 4 | -0.085 | 50 | 16 |
VME-C800 | 800 | 11 | 0-3300 | 5.5 | 0-60 | 4 | -0.08 | 65 | 25 |
The parameters are for reference only, products and capacity can be customized. |
