SED-YX Rotary Capping Machine with Cap Loader
SED-YX series rotary capping machine can select the capping system according to the bottle cap and bottle style. The constant torque capping head ensures that the capping head stops rotating after the cap meets the tightness requirements. It is suitable for products with high tightness requirements. The machine is suitable for pharmaceutical, food, cosmetic and other industries.
Product Description
Features of Rotary Capping Machine
- PLC-controlled, clear and understandable display on the touch screen
- The capping system can be selected according to the cap and bottle design
- Photoelectric sensor detection, the machine will stop when there is a bottle shortage or bottle blockage, and will automatically run after recovery
- Made of stainless steel 304, which meets the requirements of GMP standard
- The embedded buckle structure is adopted, which is easy to disassemble, clean and easy to be used and maintenance
- Frequency control of the whole machine
- The equipment can be used independently or connected with other equipment, such as counting machine and sealing machine
- Advantages of Automatic Rotary Capping Machine
Constant torque capping head ensures that the head stops rotating after the caps meet the tightness requirements, which is suitable for products with high tightness requirements (can be replaced with a pressing cap system) - The capping head can be replaced to meet the requirements of different bottle caps.
- The structure is fastened and all parts such as electrical control are sealed to avoid materials affecting the service life of electrical components
- During normal production, there is no need for specialized personnel to take care of the machine, and various automatic protection devices are equipped.
- The detection system of cap defective and no aluminum foil can be equipped (optional)
Technical Data
Model | SED-YX |
Bottle Diameter (mm) | 20-100 |
Bottle Height (mm) | 40-180 |
Capacity (bottles/min) | 20-140 |
Power (kW) | 0.3 |
Power Supply | 220V/50Hz |
Overall Dimensions (L*W*H mm) | 1850*1300*1400 |
Weight (kg) | 650 |
Application | plastic round bottle |
