SED-DJH Single Effect Vacuum Concentrator for Liquid
The Vacuum Concentrator can be operated in either vacuum or constant pressure conditions. It can be used for the concentration of water or organic solvent in many industries. It’s especially suitable for continuous concentration in vacuum conditions for heat-sensitive material (such as Chinese medicine, antibiotics, fermentation liquor, milk, juice, and alcohol extracting solution).
Product Description
Description of Single Effect Vacuum Concentrator
This Vacuum Concentrator for Liquid can be operated in either vacuum or constant pressure conditions. It can be used for the concentration of water or organic solvent in many industries. It’s especially suitable for continuous concentration in vacuum conditions for heat-sensitive material (such as Chinese medicine, antibiotics, fermentation liquor, milk, juice, and alcohol extracting solution).
Features of Single Effect Vacuum Concentrator
- The machine can be operated under a vacuum, the vacuum degree can range from -0.8 to -0.098MPa.
- Saves 30% energy because it is operated under vacuum.
- There are no dead corners making it convenient for clean.
- The machine does not require complex assembly; simply connect the electricity and water (steam and cooling) and it will be ready for operation.
- The machine is made of polished stainless steel according to GMP standards.
- The machine can be operated continuously for long durations.
Application of Single Effect Vacuum Concentrator
Technical Data
| Model | SED-300DJH | SED-500DJH | SED-1000DJH | SED-2000DJH | SED-3000DJH | SED-5000DJH | ||
| Evaporate (kg/h) | 300 | 500 | 1000 | 2000 | 3000 | 5000 | ||
| Volume (L) | 200 | 500 | 700 | 1000 | 2000 | 3000 | ||
| Work pressure (MPa) | 0.1 | |||||||
| Concentration rate | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | ||
| Vacuum (MPa) | -0.08 | |||||||
| Heat area(m²) | 5 | 8 | 15 | 30 | 45 | 65 | ||
| Dimension(m) | 2.2*0.8*2.6 | 2.7*0.9*3.5 | 3.2*0.9*3.8 | 3.6*1.3*4 | 3.6*1.4*4.5 | 4*1..6*6 | ||
