SED-QN Series Ball Type Vacuum Concentrator
This vacuum concentrator is suitable for concentrating the fluid materials of traditional Chinese herbal medicine, western medicine, glucose, starch, powders, food and milk products, certain chemical materials, and in particular, any thermal-sensitive fluids.
Product Description
Description of Ball Type Vacuum Concentrator
This vacuum concentrator is suitable for concentrating the fluid materials of traditional Chinese herbal medicine, western medicine, glucose, starch, powders, food and milk products, certain chemical materials, and especially any thermal sensitive fluids.
Our factory has carried out careful accumulation and meticulous design and reform of the equipment which raises the machine performance and quality well above its original characteristics. You can set the series concentrator with technical parameters according to your concentration.
Features of Ball Type Vacuum Concentrator
- The ball type vacuum concentrator is an evaporation equipment that is mainly composed of a concentrating tank, condenser, and storage tank for recycled liquid
- The ball type tank is easy to clean and discharge
- It uses a vacuum to decompress and concentrate, the concentration factor is higher than 1.4
Application of Ball Type Vacuum Concentrator
Technical Data
| Item | SED-300QN | SED-500QN | SED-700QN | SED-1000QN |
| Evaporating Capacity (Kg/h) | 70 | 120 | 145 | 195 |
| Nominal Volume (L) | 300 | 500 | 700 | 1000 |
| Ball Diameter (mm) | 800 | 990 | 1115 | 1250 |
| Steam Pres. (MPa) | 0.3 | |||
| Vacuum Degree (MPa) | 500-620 | |||
| Heating Area (m²) | 1.1 | 1.6 | 2 | 2.5 |
| Condensing Area (m²) | 2.4 | 3.2 | 3.5 | 4.5 |
| Weight (kg) | 380 | 450 | 630 | 950 |
| Dimension L (mm) | 1900 | 2030 | 2100 | 2335 |
| Dimension W (mm) | 1100 | 1200 | 1300 | 1520 |
| Dimension H (mm) | 2300 | 2500 | 2500 | 2785 |
| Steam Consumption (kg/h) | 77 | 132 | 159 | 214 |
| Water Consumption (kg/h) | 5700 | 8950 | 10830 | 15920 |
| Steam Inlet (mm) | 40 | 40 | 50 | 50 |
| Water Inlet/Outlet (mm) | 30 | 30 | 40 | 40 |
