SED-JHT Series Alcohol Distilling Tower
The main function of the alcohol distilling tower is to separate mixed liquids, and separate liquids by using the principle of different liquids under different conditions, such as different temperatures and different volatilities, to achieve the purification effect. The alcohol distilling tower is suitable for alcohol recovery in pharmacy, food, chemical and select other industries.
Product Description
Description of Alcohol Distilling Tower
The alcohol distillation tower is a gas-liquid contacting device for carrying out rectification. According to different operation modes, the products can be classified into continuous rectification towers and intermittent rectification towers. The heating methods of the distilling kettle include external circulation type and internal circulation type which are available for selection.
The alcohol distillation tower is suitable for alcohol recovery in pharmacy, food, chemical and select other industries. It serves to reduce production costs and enhance economic benefits. The device can distill the thin alcohol from 30-50% to 90-95%. The alcohol content of discharged residual liquid is less than or equal to 0.1%. It is a device specially used for alcohol recovery.
Features of Alcohol Distilling Tower
The device adopts a high-efficiency stainless steel corrugated filler. The parts that contact alcohol, such as the tower body, condenser, pressure stabilizer tank, and cooling coil are all made of stainless steel and ensure that the finished alcohol is free of pollution. It adopts a dismountable U-type pipe, to facilitate the cleaning of the external heating wall and an internal wall of the alcohol distilling tower.
Application of Alcohol Distilling Tower
Technical Data
| Model | SED-200JHT | SED-300JHT | SED-400JHT | SED-500JHT | SED-600JHT | SED-800JHT |
| Volume (L) | 900 | 1100 | 1600 | 2000 | 2500 | 3200 |
| Recycling Capacity (kg/h) | 45-60 | 90-100 | 150-160 | 280-300 | 420-450 | 600-630 |
| Cooling Area (m2) | 1 | 1.6 | 3 | 3 | 3 | 4.5 |
| Condensate Area (m2) | 4 | 9 | 16 | 25 | 36 | 56 |
| Steam Pressure | ||||||
| Height (mm) | 5500 | 7000 | 7000 | 7500 | 7500 | 7500 |
